Growatt Single Phase PV Panels On grid Solar Inverter 7kw 8kw 9kw 10kw
- Low stock - 2 items left
- Backordered, shipping soon
Growatt Single Phase7kw 8kw 9kw 10kw On Grid Tie PV Inverter
The unit converts the DC current generated by the photovoltaic (PV) modules to grid compliant alternating current and performs single-phase feed-in into the electricity grid.
MIN 7000-10000TL-X inverters are built according to all required safety rules. Nevertheless, improper use may cause lethal hazards for the operator or third parties, or may result in damage to the units and other property.
Important Specification of Growatt MIN series Inverter
The following are some descriptions of Growatt Min series inverter 6kw-10kw, if you need the full datasheet, please contact our sales team.
Datasheet
|
MIN 7000TL-X
|
MIN 8000TL-X
|
MIN 9000TL-X
|
MIN 10000TL-X
|
Input Data (DC)
|
||||
Max. recommended PV power
(for module STC) |
12000W
|
12000W
|
13500W
|
15000W
|
Max. DC voltage
|
600V
|
600V
|
600V
|
600V
|
Start voltage
|
100V
|
|||
Nominal voltage
|
360V
|
|||
MPP voltage range
|
60V-550V
|
60V-550V
|
60V-550V
|
60V-550V
|
No. of MPP trackers
|
2 / 2 / 3 / 3
|
|||
No. of PV strings per MPP tracker
|
1+2 / 1 +2 / 1+1+2 / 1+1+2
|
|||
Output data(AC)
|
|
|||
AC nominal power
|
7000W
|
8000W
|
9000W
|
10000W
|
Max. AC apparent power
|
7000VA
|
8000VA
|
9000VA
|
10000VA
|
Nominal AC voltage(range*)
|
Default:240V split-phase, optional:208V & 240V single phase , 183-228@208V 211-264V@240V
|
|||
AC grid frequency(range*)
|
50/60 Hz (45-55Hz/55-65 Hz)
|
|||
AC grid connection type
|
Single phase
|
Advantages of Growatt MIN series 7kw -10kw Inverter
- Type II SPD on the DC side
- AFCI function optional
- Max. efficiency 98.4%
- Dual MPP trackers
- Wide MPPT voltage range
- Future-proof battery-ready
- Touch key and OLED display
- Compact design for one-person installation
Accessories and Inverter Parts Inside the Package of Growatt MIN Series Inverter
In the following table you will find the accessories and parts inside the package of the inverter
Object
|
Description
|
Quantity
|
Object
|
Description
|
Quantity
|
A
|
Inverter
|
1
|
H
|
Plastic expansion tube
|
3
|
B
|
Quick Guide
|
1
|
I
|
Self-tapping screw
|
3
|
C
|
Mounting bracket
|
1
|
J
|
Security screw
|
1
|
D
|
AC waterproof cover
|
1
|
K
|
AC OT terminal
|
3
|
E
|
Monitor(Optional)
|
1
|
L*
|
PV Male &Female cable coupler
|
3/4
|
F
|
4PIN COM port signal connector
|
1
|
M*
|
PV Pin&Socket contacts
|
3/4
|
G
|
Waterproof connector
|
1
|
O
|
PV terminal removal tool
|
1
|
P
|
AC terminal block insulation partition
|
2
|
|||
* MIN7000-8000TL- X(E) 3 MIN9000-10000TL-X 4
|
Export Limitation Setting
If the local grid company requires to limit the output power from your inverter systems,we introduce the concept of Export Limit Rate.The ratio of your system output power divided by the rated power of the inverter is called Export Limited Rate.For example,if the local grid company only accepts 8kW from your 10kW system,then the Export Limit Rate of 10kW inverter should be 80%.
